Introducing the MAX Modular TOPPER MAX Bed Rack for Softoppers.

Fits the Ford Ranger years 1983 to 2012

Features:
- 12 gauge steel, CNC laser cut legs and crossbars.
- Extruded aluminum crossbar center sections, black anodized.
- Fully bolt together, shipped disassembled, easy to put together.
- Stainless steel hardware.
- Black textured powder coated.
- Side Plates and Top Bars have adjustable positioning.
- Crossbars have holes for mounting bike fork mounts.
-Attaches to the lip on the inside of the bed rails using No-Drill Clips. (No drilling required)
- Additional accessory panels can be purchased here.
- Additional top bars can be purchased here.

Equipped with mounting holes for the following accessories:

• MAX Universal Hi Lift Jack Brackets

• MAX Traction Board Brackets

• MAX Outboard Bike Mounts

• MAX Universal Awning Brackets

• RotoPax Fuel Packs

Available Heights:

• 21.5” (clearance under rack is 19.5”)

• 24.5” (clearance under rack is 22.5”)

• 27.75” (clearance under rack is 25.75”) (This size comes standard with our Extra Wide Accessory Panels)

Available Lengths:

• 46" long

• 58" long

Rack Weights:

• 21.5” high x 46” long - 48 pounds

• 21.5” high x 58” long - 52 pounds

• 24.5” high x 46” long - 52 pounds

• 24.5” high x 58” long - 56 pounds

• 27.75” high x 46” long - 56 pounds

• 27.75” high x 58” long - 60 pounds

Rated Capacity (evenly distributed):

• 450 pounds dynamic

• 900 pounds static

*Please allow 3 to 5 business days processing time prior to shipment. If the item is needed ASAP, email us and we will help you out.

This item ships in three boxes. You will receive three tracking numbers.
